CruzPro A60 Ammeter

-5%

€ 143,44 € 136,27

iva inclusa

Code: MTO02083

quantity

The CruzPro A60 is an ammeter with digital reading of the on-board system current data. Programmable to work with shunts between 5 and 900 Amps such as the CruzPro SH-150 and SH-450. It is possible to set 5 different backlight levels. 12/24 Vdc power supply. NMEA 0183 output.

All calibrations such as the type of Shunt are pre-set at the factory but can be changed for any particular use. By pressing a key it is possible to automatically reset the display and view the current reading from 0 to 900 Ampere.

The A60 draws only 0.017 amps and can be left running continuously. Each setting will be stored in a non-volatile memory.

Technical features

Power supply voltage: 9.5 - 33 Vdc
Absorption: 0.018 amps nominal
Operating temperature: 0 ° - 50 ° C
Display: 3 digits, 5 backlight levels
Data displayed: Ampere (Programmable with shunt from 5 - 900 Ampere)
Resolution: 0.1 Ampere with shunt less than 90 Ampere; 1 Ampere with shunt greater than 90 Ampere
Pricision: Better than +/- 3%
Output: NMEA 0183 serial at 4800 bps (Sentence $ IIXDR, I)
Embedding hole: 55 mm
